Features and Benefits:
- Precision ball bearing lubricated for life.
- Hardened stainless steel rotor.
- Optimized balance seal for minimal friction.
- SIC/ graphite seal combinition suitable for air service.
- Body available in anodized aluminum or brass.
Medium | BAR(MAX.) | ℃(MAX.) | Taper Pipe Thread | Straight Pipe Thread |
Air | 10 | 120 | 1500 | 1500 |
Coolant | 50 | 120 | 1500 | 3500 |
Hydraulic Oil | 50 | 120 | 1500 | 3500 |
Note: No Dry Running
